Lenz 10310-02 Silver Mini (wires only) DCC Decoder

The DIGITAL plus SILVER locomotive decoder has wires for hard-wire installations. It is suitable for all DC locomotives with a continuous current draw of 0.5 amps or less with a no DCC socket.

Full Specifications

• NMRA-compliant DCC locomotive decoder.
• Super smooth and silent high-frequency back-emf motor control.
• Supports Automatic Braking Control (ABC).
• Adjustable precision stopping control.
• Shunting speed on F3.
• Selectable for operation with 14/27, or 28/128 speed steps.
• Operation on conventional DC layouts is possible or can be disabled.
• Motor output = 0.5A continuous, 0.8A max.
• Motor and function outputs are protected onboard.
• Four function outputs rated at 100mA each with advanced function mapping.
• Directional or independent lighting with dimming and special effects.
• Support for multiple traction and long addresses (Loco addresses up to 9,999).
• Support for programming on the mainline (Programming on Main POM).
• Support for all forms of programming as described in NMRA RP-9.2.3.
• RailCom.
• Size: L 10.6mm x W 7.5 mm x H 2.6mm.

[/et_pb_text][/et_pb_column][et_pb_column type=”1_3″ _builder_version=”4.16″ custom_padding=”|||” global_colors_info=”{}” custom_padding__hover=”|||”][et_pb_text admin_label=”Specifications” _builder_version=”4.22.0″ text_font=”ABeeZee||||||||” text_font_size=”12px” custom_padding=”15px|15px|15px|15px” border_radii=”on|5px|5px|5px|5px” border_width_all=”2″ border_color_all=”#3aaa35″ global_colors_info=”{}”]

Decoder Specifications

Decoder Type: Wires only

Motor current (continuous): 0.5 Amp

Function outputs: 4

SUSI support: Yes (solder pads)

Stay-alive support: Yes (solder pads)

Dimensions: L10.6 x W7.5 x H2.6 mm

[/et_pb_text][et_pb_text admin_label=”Useful Information” _builder_version=”4.22.0″ text_font=”ABeeZee||||||||” custom_padding=”15px|15px|15px|15px” border_radii=”on|5px|5px|5px|5px” border_width_all=”2″ border_color_all=”#e6007e” global_colors_info=”{}”]

Useful information

Instruction Manual
